24th Edition National Grid Standard Pile
160kW Integrated Single-Gun/Dual-Gun DC Charger
The energy storage battery cluster consists of multiple packs connected in series, forming a system-level unit that achieves high-voltage output and constitutes the basic module of the energy storage power station.
Suitable for power plants, petrochemicals, metallurgy and steel rolling, light industry and textile factories and mines, residential areas, high-rise buildings, and other places.
Product Highlights
Diverse payment methods
Portable emergency use
Real-time display function
Diverse charging modes
Supports online upgrades
Flexible networking methods
Strict protection level
Accurate metering and billing
Technical parameters
| Performance Parameters | Item | Parameter |
| Appearance & Structure | Housing Material | Metal |
| Product Dimensions | 950*950*1965mm (L*D*H) | |
| Screen Size | 7 inches | |
| Installation Method | Floor-mounted | |
| Cable Length | 4m (Optional) | |
| Product Weight | 410kg | |
| Product Color | Grey & White | |
| Electrical Parameters | Rated Input Voltage | 380V ±20% |
| Rated Output Voltage | 1000V | |
| Rated Output Current | 160A | |
| Max. Output Current | 250A | |
| Standby Power Consumption | 20W | |
| Impulse Withstand Voltage | 6kV | |
| Power Frequency Withstand Voltage | 2.2kV AC/3.1kW DC | |
| Output Efficiency | ≥95% | |
| Output Configuration | Integrated Single-gun / Integrated Dual-gun | |
| Surge Protection Device (SPD) | Class C | |
| Rated Power | 160kW | |
| Environmental Adaptability | Product Noise | ≤65dB |
| Operating Altitude | ≤2000m | |
| Protection Level | IP55 | |
| Operating Temperature | -30℃~55℃ |
Note: The product description is for reference only. The actual appearance, specifications, and other information of the product are subject to the actual product sold.
