21st Edition National Grid Standard Pile
480kW split-type DC charging pile
The energy storage battery pack consists of multiple modules integrated, high-voltage high-capacity units including BMS and thermal management system, forming a complete power storage system.
Suitable for various scenarios such as small secondary substations, switching stations, industrial and mining enterprises, transportation hubs (such as airports, railways), commercial areas, high-rise buildings, highways, subways and tunnels.
Product Highlights
Diverse charging modes
Flexible payment methods Flexible payment methods
Dynamic power allocation
Small equipment footprint
Technical parameters
| Performance Parameters | Item | Parameter |
| Appearance Structure | Shell Material | Metal |
| Product Dimensions | 900*800*2100/700*240*1800 (L*D*H)(Whole Machine/Whole Pile) | |
| Screen Size | 7 inches or no screen | |
| Product Weight | 640kg | |
| Gun Cable Length | 5 m (optional) | |
| Product Color | Gray White | |
| Electrical Parameters | Rated Input Voltage | 380V±20% |
| Rated Output Voltage | 1000V | |
| Rated Output Current | 480A | |
| Single Gun Maximum Output Current | 250A | |
| Constant Power Range | 300-1000V | |
| Rated Power | 480kW | |
| Standby Power Consumption | 20W | |
| Impulse Withstand Voltage | 12kV | |
| Power Frequency Withstand Voltage | 3.5kVDC | |
| Leakage Current | ≤30mA | |
| Lightning Protection Device | Class C | |
| Output Form | Dual Machine, Four Piles | |
| Environmental Adaptation | Product Noise | ≤65dB |
| Protection Class | Whole Machine IP54/Whole Pile IP55 | |
| Operating Altitude | ≤2000m | |
| Operating Temperature | -25℃~55℃ |
Note: The product description is for reference only. The actual appearance, specifications, and other information of the product are subject to the actual product sold.
