24th Edition National Grid Standard Pile
480kW split-type DC charging pile
This product is a containerized energy storage unit pre installed with integrated battery clusters, liquid cooling systems, and fire protection. It supports high-voltage DC output and has plug and play and efficient thermal management features.
Suitable for commercial charging stations, urban fast-charging networks, and transportation hubs, providing fast and efficient charging services for electric vehicle users, optimizing energy utilization, and enhancing the charging experience.
Product Highlights
Diverse charging modes
Diverse payment methods
Wide range of functions
Small equipment footprint
Technical parameters
| Performance Parameters | Item | Parameter |
| Appearance Structure | Shell Material | Metal |
| Product Dimensions | 2004*1101*2000/564*664*1805 (L*D*H)(Whole Machine/Whole Pile) | |
| Screen Size | 7 inches | |
| Product Weight | 640kg | |
| Gun Cable Length | 4m (Optional) | |
| Product Color | Gray White | |
| Electrical Parameters | Rated Input Voltage | 380V ±20% |
| Output Voltage Range | 200-1000V | |
| Rated Output Current | 480A | |
| Single Gun Maximum Output Current | 250A/400A/600A | |
| Constant Power Range | 300-1000V | |
| Rated Power | 480kW | |
| Standby Power Consumption | N*30W | |
| Impulse Withstand Voltage | 6kV | |
| Power Frequency Withstand Voltage | 2.2kV AC/3.1kV DC | |
| Leakage Current | ≤30mA | |
| Lightning Protection Device | Class C | |
| Output Form | One Machine, Three Piles, Six Guns | |
| Environmental Adaptation | Product Noise | ≤65dB |
| Protection Class | IP55 | |
| Operating Altitude | ≤2000m | |
| Operating Temperature | -30℃~55℃ |
Note: The product description is for reference only. The actual appearance, specifications, and other information of the product are subject to the actual product sold.
