Energy Storage System
5.016MWh liquid-cooled energy storage DC container
This product is a 480kW split DC charging stack that supports 6 outputs and can be configured with three dual output interfaces or six single output interface charging terminals. The maximum power can reach 480kW. It adopts a split structure design, with centralized charging power configuration and multiple charging ports sharing charging power. It has the ability to cooperatively control multiple charging ports to charge according to multiple charging strategies.
Industrial parks, data centers, wind and solar power generation with energy storage, shared energy storage, independent energy storage.
Product Highlights
Simple installation and manufacturing
High-quality manufacturing
Four charging modes
High degree of standardization
Technical parameters
| Performance Parameters | Performance Parameters | ||
| Cell Type | LFP-314Ah | Operating Altitude | ≤3000m(derating above 3000m) |
| Rated Energy | 5.018MWh | Operating Relative Humidity | 0%-95%RH, no condensation |
| String Configuration | 1P416S*12 | Communication Method | CAN/RS485/Ethernet |
| Rated Voltage | 1331.2V | Cooling Method | Liquid Cooling |
| Operating Voltage Range | 1164.8~1476.8V | Fire Protection Method | Perfluorocyclohexanone + PACK-level fire protection |
| Rated Charge/Discharge Frequency | 0.5P | Protection Class | IP54 |
| Allowable Operating Temperature | -20~55°C(derating above 45°C) | Dimensions (W*D*H) | 6280*2580*2998mm |
| Cycle Life | ≥10000 cycles, (25±2°C, 95%DOD,70%EOL) | Weight | Approximately 50t |
Note: The product description is for reference only. The actual appearance, specifications, and other information of the product are subject to the actual product sold.
