Data Collection Terminal
DJTH23-NRZS8052 Concentrator Type I
The 250A split-type DC charging terminal with dual guns provides a high-efficiency charging solution for electric vehicles. It features a dual-gun configuration, supporting simultaneous charging of two electric vehicles, greatly improving the operational efficiency of charging stations. The product features real-time monitoring and diverse payment methods, has comprehensive protection functions, and supports online upgrades, ensuring that the technology remains up-to-date. Its robust structure and high protection rating make it suitable for harsh outdoor working environments.
Product Highlights
Electricity metering
Focuses on metering, distribution, and optimized use of electrical energy on the user side.
Power quality monitoring
Key structural components are originally imported from Germany, ensuring consistent global quality.
Data acquisition
The cabinet is small in size, saving space, and uses modular plug-and-play technology for convenient on-site assembly and flexible configurations. The upper part of the cabinet houses the busbar compartment, the front part houses the electrical equipment compartment, and the rear part houses the cable entry and exit compartment. Each compartment is isolated by steel plates or insulating plates, ensuring safety and reliability.
Data storage
Corrosion-resistant, fully sealed aviation connector design ensures high reliability of the power distribution automation interface, requiring long-term maintenance-free or minimal maintenance.
Remote communication
It records various key events in detail, such as programming, time synchronization, power failure, remote switching, and cover opening.
Technical parameters
| Performance Parameter Table | |
| Item Name | Main Technical Parameters |
| Meter Constant | 10000imp/kWh |
| Accuracy Class | Active: Class C; Reactive: Class 2 |
| Specification | 3×1.5(6)A |
| Reference Voltage | 3×220V/380V |
| Frequency | 50Hz |
| Power Consumption | ≤15W 25VA in non-communication state |
| Limit Operating Range | (1±30%)Un |
| Communication Interface | 1 IR port, 2 RS485 ports, 2 remote signaling inputs, 1 CAN port |
| Daily Timekeeping Error | ≤±0.5s/d |
| Overall Dimensions | 290mm (H) × 180mm (W) × 95mm (D) |
