Data Collection Terminal
DJTL33-NRZS8040 Concentrator Type II
The 60-160kW integrated single/dual-gun DC charger features high power output and flexible charging methods, meeting the fast charging needs in different scenarios. The product supports real-time monitoring and multiple payment methods, and has comprehensive protection functions to ensure safe and reliable charging. Easy to install, supports online upgrades, and adapts to harsh outdoor environments, making it an ideal choice for commercial parking lots and public charging stations.
Suitable for high load density areas, cable distribution networks, substations, wind farms, and complex application scenarios such as subways. Smart meter networks, smart distribution area upgrades, photovoltaic grid connection monitoring, demand-side response
Product Highlights
Data acquisition
Collects real-time energy meter readings, daily zero-point frozen energy readings, and meter reading day zero-point frozen energy readings.
Data management and storage
对采集数据进行分类存储，如日冻结数据、抄表日冻结数据、曲线数据、历史月数据等。
Key user data acquisition
It can collect the total three-phase voltage and current on the low-voltage side of the distribution transformer in real time, realizing basic distribution transformer monitoring functions.
Electricity meter operation monitoring
The cable compartment is spacious, with protective covers for secondary wiring; explosion-proof glass windows provide direct monitoring of cable connections.
Technical parameters
| Performance Parameter Table | |
| Item Name | Main Technical Parameters |
| Ground Fault Immunity | 1.9 times nominal voltage |
| Accuracy Class | Active: Class C; Reactive: Class 2 |
| Reference Voltage | ~220V |
| Frequency | 50Hz |
| Power Consumption | ≤3W 5VA in non-communication state |
| Limit Operating Range | 0.8Un~1.2Un |
| Communication Interface | 3 RS485 ports, 1 IR port, 1 USB port, 1 Ethernet port |
| Daily Timekeeping Error | ≤±0.5s/d |
| Overall Dimensions | 160mm (H) × 112mm (W) × 71mm (D) |
