Smart Low Voltage Complete Switchgear
Siemens SIVACON 8PT series intelligent low-voltage distribution cabinet
The 480kW split type DC charging stack has various charging modes and flexible payment methods, dynamically adjusting power to meet different charging needs. Compact in size, easy to install, supports multiple charging gun configurations, and meets fast charging needs. High charging efficiency, strict protection level, and adaptability to various environmental conditions make it an ideal choice for public charging stations and commercial charging venues.
Intelligent management of distribution areas, power quality optimization, access and management of electric vehicle charging piles
Product Highlights
Uses standardized modules that have undergone type testing, resulting in high system safety.
The functional compartment uses metal partitions and independent pressure relief channels, meeting the IAC-A arc-fault design standard for safety and reliability.
Standardization and interchangeability significantly reduce user operation and maintenance costs.
Features multiple protection functions, including overload, short circuit, and ground fault protection.
Fully sealed, fully insulated, and without exposed parts, ensuring safety and reliability.
Technical parameters
| Item | Unit | Data | |||
| Enclosure Protection Class | / | IP4X | |||
| Operating Temperature | ℃ | -25~+40 | |||
| Overvoltage Category | / | IV | |||
| Material Group | / |
IIIa | |||
| Rated Voltage | kV | 0.4 | |||
| Rated Frequency | Hz | 50 | |||
| Rated Insulation Voltage (Incoming & Feeder Cabinet) | kV | 1 | |||
| Rated Insulation Voltage (Control Cabinet) | kV | 0.8 | |||
| Rated Current of Horizontal Main Busbar | A | 1600-400 | 2500-1000 | 4000-1600 | 6300-4000 |
| Rated Current of Vertical Distribution Busbar | A | 800-200 | 1500-1000 | 1800-400 | 2400-1200 |
| Rated Short-time Withstand Current of Horizontal Main Busbar / 1s | kA | 30 | 50 | 80 | 100 |
| Rated Short-time Withstand Current of Vertical Distribution Busbar / 1s | kA | 30 | 50 | 65 | 80 |
| Rated Peak Withstand Current of Horizontal Main Busbar | kA | 63 | 105 | 176 | 220 |
| Rated Peak Withstand Current of Vertical Distribution Busbar | kA | 63 | 105 | 143 | 176 |
| Standard Cabinet Dimensions (W*D*H) | mm | (600/700/800)*1000*2200 | (800/900/1000)*1000*2200 | ||
