Smart Ring Main Unit
XGW-12 Primary and secondary integrated ring network box
This product is a 120kW vertical integrated dual gun DC charger designed according to the design specifications of Southern Power Grid. It can provide customers with reliable, safe, and fast DC charging services, meeting the charging needs of electric vehicles. The product provides multiple communication interfaces for real-time communication with station level monitoring centers or operation management centers, uploading real-time charging information. The product has a self checking function, which immediately stops charging when abnormalities or faults are detected, ensuring the personal and vehicle safety of the user during the charging process.
Suitable for underground parking lots in residential areas, private parking spaces, employee parking lots, and other slow charging scenarios, providing overnight charging for new energy passenger vehicles. Suitable for large shopping malls, bus stations, cargo terminals, community parking lots, logistics vehicle depots, and other scenarios.
Product Highlights
Uses pre-fabricated touchable silicone rubber cable heads, fully sealed, fully insulated, maintenance-free, reliably ensuring personal safety.
Compact structure and small size, easy installation and simple operation.
Interchangeable trolleys (circuit breakers/transformers, etc.) of the same specifications; double locking in test/working positions; interlocking anti-misoperation program reduces the risk of misoperation.
Can be selected for trolley-type or fixed-type installation, flexible configuration.
It complies with the latest IEC60439-1, GB7251.12, and other standards, and has been certified by authoritative laboratories.
It monitors the operating status of the energy meter, including phase sequence abnormalities and energy meter cover opening records.
Technical parameters
| Item | Unit | Data |
| Enclosure Protection Rating | IP33D, IP43, IP44, IK10 | |
| Rated Short-Time Withstand Current of Ground Connection | kA/4s | 17.4, 21.7, 27.3 |
| Rated Peak Withstand Current of Ground Connection | kA | 43.5, 54.6, 69.3 |
| Rated Voltage, Rated Current, Rated Short-Circuit Breaking Current, Rated Short-Circuit Making Current, Rated Short-Time Withstand Current, Electrical Life, Mechanical Life, etc. | Refer to the technical parameters of supporting switchgear | |
| Overall Dimensions | Customizable |
