Energy Storage Battery Cluster
The 20kW portable single-gun DC charger provides electric vehicle users with a flexible charging solution thanks to its portability, ease of operation, and comprehensive protection features. The product has a compact appearance, light weight, and is easy to carry and move. It boasts efficient charging performance and stable electrical parameters, with a maximum output current of up to 66.7A and a rated power of 20kW, supporting fast charging. Its wide operating temperature range makes it suitable for different environmental conditions, making it an ideal choice for outdoor and emergency charging.
Suitable for large public charging stations, electric vehicle fast charging centers, logistics and public transportation charging facilities.
Technical parameters
| Category | GHALB07682801 | GHALB07683141 | GHALB12802801 | GHLLBO8323141 | GHLLB13313141 |
| Cell Type | LFP-280Ah | LFP-314Ah | LFP-280Ah | LFP-314Ah | LFP-314Ah |
| Battery Cluster Configuration | 1P240S | 1P240S | 1P400S | 1P260S | 1P416S |
| Rated Voltage | 768V | 768V | 1280V | 832V | 1331.2V |
| Rated Energy | 215.04kWh | 241.152kWh | 358.4kWh | 261.248kWh | 417.997kWh |
| Operating Voltage Range | 600~876V | 600~876V | 1000~1460V | 650~949V | 1040~1497.6V |
| Rated Charge/Discharge Power | 0.5P | 0.5P | 0.5P | 0.5P | 0.5P |
| Voltage Platform | 1000V | 1000V | 1500V | 1000V | 1500V |
| Cooling Type | Air Cooling | Air Cooling | Air Cooling | Liquid Cooling | Liquid Cooling |
| Weight | 1940±20kg | 1980±20kg | 3225±20kg | 1760±30kg | 2810±30kg |
| Dimensions (W*D*H) | 958*814*2003mm | 958*814*2243mm | 1427*814*2243mm | 924*1250*1460mm | 924*1250*2230mm |
