400/600A Split-Type Liquid-Cooled DC Charging Terminal - Dual-Gun
The GCS type low-voltage withdrawable switchgear is used for power conversion, distribution, and control in low-voltage power distribution systems with AC 50-60Hz, rated current of 4000A and below, and rated operating voltage of 400V and below, serving as a power, distribution, and motor control center, and for capacitor compensation. It can meet the needs of places requiring a high degree of automation and computer interfaces, and complies with relevant technical standards such as IEC61439-1 and GB7251.
Suitable for commercial parking lots, public charging stations, logistics parks, etc., providing efficient and safe charging services for electric vehicles.
Product Highlights
Real-time display function
Online payment upgrade
Complete protection functions
Diverse charging modes
Strict protection level
Supports online upgrades
Accurate metering and billing
Technical parameters
| Performance Parameters | Item | Parameter |
| Appearance & Structure | Housing Material | Metal |
| Product Dimensions | 500*400*1600mm (L*D*H) | |
| Screen Size | 7 inches | |
| Installation Method | Floor-mounted | |
| Cable Length | 5m (Optional) | |
| Product Weight | 180kg | |
| Product Color | Silver + Deep Space Gray | |
| Electrical Parameters | Rated Input Voltage | 1000V |
| Rated Output Voltage | 1000V | |
| Rated Output Current | 400A / 600A | |
| Standby Power Consumption | 20W | |
| Impulse Withstand Voltage | 6kV | |
| Power Frequency Withstand Voltage | DC4.2 kV | |
| Output Configuration | Dual Connectors | |
| Environmental Adaptability | Operating Temperature | -25℃~55℃ |
| Operating Altitude | ≤2000m | |
| Protection Level | IP54 |
Note: The product description is for reference only. The actual appearance, specifications, and other information of the product are subject to the actual product sold.
