600-960kW split-type DC charging pile
The DJS1801 DC energy meter is made of high-performance integrated circuits and high-quality components, processed using advanced production technology. The meter consists of a measurement unit, a data processing unit, and a communication unit, and has functions such as energy measurement, data processing, real-time monitoring, automatic control, and information exchange. All indicators comply with the technical requirements of GB/T33708-2017 Static DC Energy Meter.
Suitable for power plants, substations, industrial and mining enterprises, large buildings and hotels, airports, docks, and communication centers such as broadcasting and television.
Product Highlights
Complete protection functions
Flexible payment methods
Dynamic power allocation
Small equipment footprint
Technical parameters
| Performance Parameters | Item | Parameter |
| Appearance Structure | Shell Material | Metal |
| Product Dimensions | 1600*800*1950mm（L*D*H） | |
| Screen Size | No Screen | |
| Product Weight | Approximately 700kg | |
| Installation Method | Floor Installation | |
| Product Color | Silver+Deep Space Gray | |
| Electrical Parameters | Rated Input Voltage | 380V±20% |
| Rated Output Voltage | 1000V | |
| Rated Output Current | 960A | |
| Single Gun Maximum Output Current | Fast Charging Terminal: 250A/300A Ultra-fast Charging Terminal: 600A | |
| Rated Power | 960kW | |
| Standby Power Consumption | 20W | |
| Impulse Withstand Voltage | 6kV | |
| Power Frequency Withstand Voltage | DC4.2 kV | |
| Leakage Current | ≤ 30mA | |
| Lightning Protection Device | Class C | |
| Output Form | 12 Channels | |
| Environmental Adaptation | Product Noise | Class Ⅱ |
| Protection Class | IP54 | |
| Operating Altitude | ≤2000m | |
| Operating Temperature | -25℃~55℃ |
Note: The product description is for reference only. The actual appearance, specifications, and other information of the product are subject to the actual product sold.
