Energy Storage System
Photovoltaic and energy storage integrated machine
The 160kW split type dual machine four gun charging stack provides users with convenient charging services through its flexible networking and diverse payment methods. Equipped with real-time monitoring and strict protection functions, supporting online upgrades, and possessing high performance and reliability. Suitable for various charging scenarios, meeting the fast charging needs of electric vehicles and improving the operational efficiency of charging stations.
Suitable for highway service areas, large parking lots, and public charging stations, providing convenient and efficient charging solutions for electric vehicle users.
Product Highlights
Multi-level power protection
Wide range of functions
Green and efficient
Technical parameters
| Product Specifications | 125kW-241kWh | Product Specifications | 125kW-241kWh |
| Battery Type | LFP | Rated Frequency | 50Hz |
| System Energy | 241kWh | System Isolation Method | Transformer |
| Charge/Discharge Power | 0.5P | Operating Temperature | -20~55℃ |
| Battery Rated Voltage | DC768V | Relative Humidity | 0%~95%RH，no condensation |
| Battery Voltage Range | DC672-876V | Diesel Generator Interface | Optional |
| Cycle Life | >8000 cycles | Noise | <75dB |
| PV Input Power | 125kW | Communication Method | CAN 485 Ethernet |
| PV Input Voltage | DDC250-650V | Operation Mode | Grid-connected/Off-grid |
| PV Maximum Current | 480A | Protection Class | IP54 |
| Output Line System | 3W+PE+N | Cooling Method | Intelligent Air Cooling |
| Rated Power | 125kW | Fire Protection | Aerosol |
| AC Rated Voltage | 400V | Dimensions (W*D*H) | 2492*1260*2300mm |
| Voltage Range | -15%~+15% | Weight | Approximately 4.5t |
Note: The product description is for reference only. The actual appearance, specifications, and other information of the product are subject to the actual product sold.
