Energy Storage System
Photovoltaic and energy storage integrated machine
The XGW series standard outdoor ring network switch station has a simple appearance and clear compartments. Multiple plate options can be selected and configured according to user requirements, including cold-rolled steel plate, aluminum zinc coated plate, and stainless steel plate; Materials with a thickness of no less than 2.0 millimeters are used for different boards, and the surface is treated with spray anti-corrosion coating. This product has excellent sealing box waterproof measures, and skeleton sealing strips or sealing cotton are installed at all gaps of the switch station; Waterproof grooves are left at the welding points of the top cover to ensure that rainwater does not enter the interior of the switch station.
Product Highlights
Safe and reliable
Intelligent power distribution
Green and efficient
Technical parameters
| Product Specification | 250kW-482kWh | Product Specification | 250kW-482kWh |
| Battery Type | LFP | System Isolation Method | Transformer |
| System Energy | 482kWh | Operating Temperature | -20~55℃ |
| Charge/Discharge Power | 0.5P | Relative Humidity | 0%~95%RH, No Condensation |
| Battery Rated Voltage | DC768V | Diesel Generator Interface | Optional |
| Battery Voltage Range | DC672-876V | Noise | Less than 75dB |
| Cycle Life | More than 8000 Cycles | Communication Interface | CAN 485 Ethernet |
| PV Input Power | 250kW | Operating Mode | Grid-Tied & Off-Grid |
| PV Input Voltage | DC250-650V | Protection Rating | IP54 |
| PV Max Current | 800A | Cooling Method | Smart Air Cooling |
| Output Wiring System | 3W+PE+N | Fire Protection | Aerosol |
| Rated Power | 250kW | Dimensions (W*D*H) | Electrical Cabinet: 1350*1000*2300mm |
| AC Rated Voltage | 400V | Battery Cabinet: 1060*1260*2300mm | |
| Voltage Range | -15%~+15% | Weight | Approx. 6.5t |
| Rated Frequency | 50Hz |
