Sodium-Ion Liquid-Cooled Integrated Cabinet
This product is a 160kW integrated single-gun/dual-gun DC charger. This cabinet-type charger has a rated power of 160kW and supports single-gun/dual-gun output, providing customers with reliable, safe, and fast DC charging services to meet the charging needs of electric vehicles. The product provides multiple communication interfaces for real-time communication with the station-level monitoring center or operation management center, uploading real-time charging information. The product has a self-checking function; it immediately stops charging when an abnormality or fault is detected, ensuring the safety of users and vehicles during the charging process.
Suitable for highway service areas, urban public charging stations, large commercial parking lots, etc., providing fast and safe charging services for electric vehicles, especially suitable for occasions requiring high-power fast charging.
Product Highlights
Safe and reliable
High magnification
Long lifespan
High efficiency
Technical parameters
| Technical Specifications | ||
| DC Side Parameters | Cell Type | Sodium-ion |
| Rated Energy | 150kWh | |
| String Configuration | 1P288S | |
| Rated Voltage | 820V | |
| Operating Voltage Range | 600-950V | |
| Rated Power / Discharge Power | 0.5P | |
| AC Side Parameters | Rated Power | 80kW |
| Maximum Power | 88kW | |
| Rated Voltage | 400V | |
| Rated Frequency | 50Hz | |
| Wiring Configuration | 3W3L/3W4L | |
| System Parameters | System Efficiency | 90% (Max) |
| Cycle Life | ≥10,000 cycles, (25±2°C, 95% DOD; 70% EOL) | |
| Cooling Method | Liquid Cooling | |
| Protection Level | IP54 | |
| Fire Protection | Pack Level + Enclosure Level | |
| Operating Temperature | -40~55°C (Derating above 45°C) | |
| Operating Relative Humidity | 0-95% RH, No Condensation | |
| Operating Altitude | ≤3000m (Derating above 3000m) | |
| Noise | ≤75dB | |
| Communication Interface | CAN/RS485/Ethernet | |
| Dimensions (L*W*H) | 1050*1365*2650mm | |
| Weight | Approx. 2.8t | |
