7kW iron shell wall-mounted single-gun AC charging pile (with screen)
The DDZY1800-M single-phase cost control intelligent energy meter is made of high-performance integrated circuits and high-quality components, processed using advanced production technology. The meter consists of a measuring unit, a data processing unit, and a communication unit, and has functions such as energy measurement, information storage and processing, real-time monitoring, automatic control, and information exchange. All indicators comply with the latest standards of State Grid Corporation of China for smart energy meters.
Perfectly adapted to harsh environments such as blizzards, frequent floods, and high pollution, and widely used in diverse scenarios such as industrial parks, residential areas, streets, airports, and commercial buildings.
Product Highlights
Simple installation and operation
Diverse payment methods
Complete protection functions
Real-time display function
Strict protection level
Supports online upgrades
Technical parameters
| Performance Parameters | Item | Parameter |
| Appearance Structure | Shell Material | Metal |
| Product Dimensions | 280*130*400mm（L*D*H） | |
| Screen Requirement | 4.3 inches screen (optional) | |
| Installation Method | Wall-mounted/Column Installation | |
| Gun Cable Length | 5m (optional) | |
| Product Weight | 10kg | |
| Product Color | Green and White | |
| Electrical Parameters | Rated Voltage | 220V±20% |
| Rated Current | 32A | |
| Rated Power | 7kW | |
| Standby Power Consumption | 5W | |
| Impulse Withstand Voltage | 2.5kV | |
| Power Frequency Withstand Voltage | 1.5kV AC | |
| Leakage Current | ≤30mA | |
| Output Form | Single Gun | |
| Lightning Protection Device | Class C | |
| Environmental Adaptation | Operating Temperature | -30℃~60℃ |
| Operating Altitude | ≤2000m | |
| Protection Class | IP54 | |
| Cooling Method | Natural Cooling |
