Charger
180-240kW integrated single/dual-gun DC charger
JGSIS-12 solid insulated ring main unit adopts solid insulation materials to seal switches and key components, ensuring that no live parts are exposed. It not only has a compact structure, but also achieves full insulation, long service life, and maintenance free. Specially designed for 12kV rated voltage and 630A rated current, and meets the requirements of State Grid's standardized customized solutions. It has excellent electrical insulation strength and arc resistance performance, ensuring safe operation; Compact size and structure, saving installation space; Modular design, easy to maintain and upgrade, strong adaptability; At the same time, it has remote intelligent control and monitoring functions to achieve intelligent management of the power system.
Suitable for large charging stations, highway charging stations, freight terminals, bus depots, logistics depots, and locations with limited installation space.
Product Highlights
Real-time display function
Diverse payment methods
Complete protection functions
Diverse charging modes
Flexible networking methods
Strict protection level
Supports online upgrades
Accurate metering and billing
Technical parameters
| Performance Parameters | Item | Parameter |
| Appearance Structure | Shell Material | Metal |
| Product Dimensions | 750*600*1880mm（L*D*H） | |
| Screen Size | 7 inches | |
| Installation Method | Floor Installation | |
| Gun Cable Length | 5m（Optional） | |
| Product Weight | 380kg （Weight Range: 320-380kg） | |
| Product Color | Silver+Deep Space Gray | |
| Electrical Parameters | Rated Input Voltage | 380V±20% AC |
| Rated Output Voltage | 1000V DC | |
| Rated Output Current | 240A | |
| Maximum Output Current | 250A | |
| Standby Power Consumption | 20W | |
| Impulse Withstand Voltage | 6kV | |
| Power Frequency Withstand Voltage | DC4.2 kV | |
| Output Efficiency | ≥ 95% | |
| Output Form | Integrated Dual Guns | |
| Lightning Protection Device | Class C | |
| Rated Power | 240kW | |
| Environmental Adaptation | Product Noise | Class Ⅱ |
| Operating Altitude | ≤2000m | |
| Protection Class | IP54 | |
| Operating Temperature | -25℃~55℃ |
