320-400kW Integrated Dual-Gun DC Charger
The 320-400kW integrated dual-gun DC charger provides a fast and convenient charging experience for electric vehicles with its excellent charging efficiency and dual-gun configuration. The product features real-time monitoring, flexible payment methods, and comprehensive protection functions, ensuring a safe and stable charging process. It supports online upgrades, is suitable for outdoor environments, and is ideal for highway service areas and large charging stations, meeting future electric vehicle charging needs.
Suitable for highway service areas, large parking lots, public charging stations, etc., providing convenient and efficient charging solutions for electric vehicle users.
Product Highlights
Simple installation and operation
Diverse payment methods
Complete protection functions
Diverse charging modes
Flexible networking methods
Strict protection level
Supports online upgrades
Accurate metering and billing
Technical parameters
| Performance Parameters | Item | Parameter |
| Appearance & Structure | Shell Material | Metal |
| Product Dimensions | 800*776*1880mm (L*D*H) | |
| Screen Size | 7 inches | |
| Installation Method | Floor-mounted | |
| Gun Cable Length | 5m (optional) | |
| Product Weight | 550kg (Weight Range: 490-550kg) | |
| Product Color | Silver + Space Gray | |
| Electrical Parameters | Rated Input Voltage | 380V±20% |
| Rated Output Voltage | 1000V | |
| Rated Output Current | 400A | |
| Max Output Current per Gun | 250A/300A | |
| Rated Power | 400kW | |
| Standby Power Consumption | 20W | |
| Impulse Withstand Voltage | 6kV | |
| Power Frequency Withstand Voltage | DC4.2 kV | |
| Output Efficiency | ≥ 95% | |
| Output Method | Integrated Dual Gun | |
| Lightning Protection Device | Class C | |
| Charging Mode | Dual Gun Equal Power Output | |
| Environmental Adaptability | Product Noise | Class Ⅱ |
| Operating Altitude | ≤2000m | |
| Protection Level | IP54 | |
| Operating Temperature | -25℃~55℃ |
