Ac Charging Pile
7kW Injection Molding Wall-Mounted Single-Gun AC Charging Pile (with Screen)
The 7kW wall-mounted single-gun AC charging pile (with screen) provides a reliable single-phase AC power supply for electric vehicles. It features a wide range of charging functions, supports multiple payment methods, and offers diverse payment options. With a strict protection rating, support for online upgrades, stable electrical parameters, and accurate metering and billing, it ensures charging safety. Its compact design facilitates installation in various locations and is suitable for diverse charging scenarios, meeting the charging needs of different users.
Product Highlights
Convenient charging
Diverse payment methods
Complete protection functions
Dynamic power allocation
Flexible networking methods
Strict protection level
Supports online upgrades
Accurate metering and billing
Technical parameters
| Performance Parameters | Item | Parameter |
| Appearance & Structure | Shell Material | PC+ABS |
| Product Dimensions | 248*90*1303mm (L*D*H) | |
| Screen Requirement | 4.3-inch screen (optional) | |
| Installation Method | Wall-mounted/Pole-mounted | |
| Gun Cable Length | 3.5m (optional) | |
| Product Weight | 4.7kg (excluding pole) | |
| Product Color | Silver Black | |
| Electrical Parameters | Rated Voltage | 220V±20% |
| Rated Current | 32A | |
| Rated Power | 7kW | |
| Standby Power Consumption | 5W | |
| Impulse Withstand Voltage | 2.5kV | |
| Power Frequency Withstand Voltage | 1.5kV AC | |
| Leakage Current | ≤30mA | |
| Output Method | Single Gun | |
| Lightning Protection Device | Class C | |
| Environmental Adaptability | Operating Temperature | -30℃~60℃ |
| Operating Altitude | ≤2000m | |
| Protection Level | IP66 | |
| Cooling Method | Natural Cooling |
Note: The product description is for reference only. The actual appearance, specifications, and other information of the product are subject to the actual product sold.
